Power Supply – 12 to 9 VDC, for use with AKCP 9 VDC cameras

Power Supply – 12 to 9 VDC, for use with AKCP 9 VDC cameras

$70.00

Add to Quote
SKU: 12VDC Category:

Description

12 VDC Power Supply

DC to DC converter which generates an output of 9.0 volts

This DC power supply comes in an external box for use with all AKCP sensorProbe and securityProbe devices.

Additional information

Option

12 VDC Power Supply

AKCP has implemented the 12-20 VDC input power supply. The product is a DC to DC converter which generates an output of 9.0 volts. This DC power supply comes in an external box for use with all AKCP sensorProbe and securityProbe devices.

This power supply includes a redundant second input channel which is automatically activated in the event of primary channel failure, and over-voltage protection, protection against input voltage reversal.



PCB with all components assembled

Specifications

Specifications

Input Range 12 – 20 VDC
Output 9.0 VDC
Power Output 13.5 Watt
Reversed Protection Yes
Dual Input Yes
Cooling Free Air Convection
Over Voltage Protection Up to 60 VDC 10 ms
Operating Temperature Range -20 to +60 Celsius
Input/Output Isolation No
